Three forms of Count modes
-
You can select three forms of Count modes by pushing buttons on the front panel.
In the Count mode 1, two channels operate independently.
In the Count mode 2 and 3, output is controlled by two setting values for one Counter. 　　　　
|
Easy-to-change Count values by panel operation
-
Without applying Count signals, you can change the Count value by the front panel operation. 　　　　
|
Prohibition of unnecessary operations
-
PS-321 has the operation prohibition function to prevent errors in operations. 　　　　
|
Independent SSR and open collector output
-
Each channel has SSR and open collector output. Four outputs or less are available. 　　　　
|
Variety of output forms
-
You can select out of 4 output forms in the Count mode 1 and 15 forms in the Count mode 2/3.You can select them by the device setting.
SSR and open collector can be set separately. 　　　　
|
Counter control functions such as Count interruption and Count reset
-
In the Count mode 2/3, the Count input 2 can be also utilized as a Counter control input. 　　　　
|
Built-in SSR for output
-
ACSSR or DCSSR for output can be installed. To replace SSRs, remove the back panel. Use the SSR specified by Sugiyama Electric System Inc. 　　　　
|
Remote control available (OPTION)
-
Most operations can be remotely controlled by commands from such devices as the programmable controller. However, optional settings are required.
|
